0.7J Spring Impact Hammer test Device IEC60068

Brand Name : Lonroy

Place of Origin : China

Model Number : 0.7J

MOQ : 1

Price : Negotaible

Length : 211mm

Weight : 1250g

Outer Diameter : 50mm

Hammer Weight : 60g

Hammer Radius : 10mm

Release Force : <10N

Impact Components : 250g

Hammer Material : Polyethylene

Impact Energy : 0.7J

Energy Error : ±0.05J

Impact Types : 0.14J, 0.20J, 0.35J, 0.50J, 0.70J, 1.00J, 2.0J

Standard Compliance : IEC60068-2-75, IEC60884, UL1244

Impact Energy Range : 0.14J to 2.0J

Hammer Head Material : White polyethylene

Impact Component Weight : 250g

Certification : ISO ASTM CE

Packaging Details : Wooden package

Delivery Time : 5-8 work days

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 200

Contact Now

0.7J spring impact hammer test device IEC60068

Standard: IEC60068-2-75 IEC60884 UL1244

Technical parameters:
Length:211mm
Weight:1250g
OD : 50mm
Hammer Weight :60g
Hammer Radius:10mm
The release force of impact: <10N
Impact Components: Including the hit ball handle the hammer ,weight 250g
Hammer head is made from white polyethylene imine first
Types: Spring Operated Impact Hammer/0.14J/0.20J/0.35J/0.50J/0.70J/1.00J/ 2.0J

0.7J spring impact hammer test device IEC60068
Spring impact hammer is designed according to the IEC60068-2-75 for testing the resistance of impact of electrical and electronic products. Spring impact hammer is the necessary test probe to check the safety performance of enclosure of electrical products under the condition of external mechanical forces.

It is used for the mechanical robustness testing of domestic and similar electrical appliances, electronic products, such as lights, enclosure of electrical accessories, lever, handle, knobs, indicator lights, signal lights, lampshades and so on.

Spring impact hammer can make sure that the tested products can withstand the possibility of reckless operations and other accidents. The electrical appliances can run safe and reliable and won’t cause harm to people.

0.7J spring impact hammer test device IEC60068

Single Impact Energy Error
0.14J ±0.014J
0.20J ±0.020J
0.35J ±0.03J
0.50J ±0.04J

0.70J

 ±0.05J
1.00J

±0.05J
2.00J

±0.10J
